Source Your P120 Directional Control Valves from a Trusted Manufacturer

Metodo di Controllo:Manuale

Spoo:2 Spole

Portata nominale:120 L/min (31,7 US gpm)

Pressione massima:250 bar (3600 psi)

Attacco di ingresso:G1

Attacco di uscita:G1

Dimensione attacco:G1

Marchio:BXHS

Tipo di prodotto:Valvola direzionale monoblocco

Serie di prodotti:Serie P120 Valvola direzionale monoblocco

Dimensioni dell'imballaggio:30*39*17

Peso lordo:19.00 kg

Disponibilità: In magazzino

1118 Le visualizzazioni cercano questo prodotto

Source Your P120 Directional Control Valves from a Trusted Manufacturer

Source Your P120 Directional Control Valves from a Trusted Manufacturer

Source Your P120 Directional Control Valves from a Trusted Manufacturer drawing image

This P120 Series 12V Hydraulic Spool Valve is a 2-section, monoblock valve designed for directional control applications. It offers a rated flow of 120 L/min and a maximum pressure of 250 bar, making it suitable for a wide range of machinery, including material handling, construction, agriculture, and industrial vehicles.

Serie P120 Valvola direzionale monoblocco Parametri
Metodo di Controllo Manuale, Cavo, Joystick, Manuale e joystick
Spoo 1 Spola, 2 Spole, 3 Spole, 4 Spole
Portata nominale 120 L/min (31,7 US gpm)
Pressione massima 250 bar (3600 psi)
Attacco di ingresso G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Attacco di uscita G1, SAE 16, 1 NPT, M36×2
Dimensione attacco G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Sezione Sezione 1, Sezione 2, Sezione 3, Sezione 4
Tipo di struttura Valvola monoblocco
Intervallo di temperatura ambiente -40°C to +80°C (-40°F to +176°F)
Intervallo di viscosità operativa 15 - 75 mm²/s (15 cSt to 75 cSt)

The P120 Series 12V Hydraulic Spool Valve is a reliable and durable solution for your directional control needs. This manual control valve features a 2-section, monoblock design with a rated flow of 120 L/min and a maximum pressure of 250 bar. It is suitable for operating viscosities from 15 to 75 mm²/s and can operate in ambient temperatures ranging from -40°C to +80°C. This valve is ideal for a variety of applications, including material handling equipment like telehandlers and forklifts, construction machinery such as all-terrain cranes and excavators, agricultural equipment, and industrial vehicles. With its robust construction and high performance, this P120 Series valve ensures reliable operation in demanding environments.
