P40-G12-G38 Hydraulic Valve: Trusted Choice for Industrial Applications

Metodo di Controllo:Manuale

Spoo:4 Spole

Portata nominale:40 L/min (10.5 US gpm)

Pressione massima:250 bar (3600 psi)

Attacco di ingresso:G1/2

Attacco di uscita:G1/2

Dimensione attacco:G3/8

Marchio:BXHS

Tipo di prodotto:Valvola direzionale monoblocco

Serie di prodotti:Serie P40 Valvola direzionale monoblocco

Dimensioni dell'imballaggio:24*23*13

Peso lordo:9.00 kg

Disponibilità: In magazzino

976 Le visualizzazioni cercano questo prodotto

P40-G12-G38 Hydraulic Valve: Trusted Choice for Industrial Applications

P40-G12-G38 Hydraulic Valve: Trusted Choice for Industrial Applications

P40-G12-G38 Hydraulic Valve: Trusted Choice for Industrial Applications drawing image

The P40-G12-G38 Hydraulic Valve is a robust and reliable 4-section, manually controlled monoblock valve designed for a wide range of industrial applications, including construction, material handling, agriculture, and industrial vehicles. It offers high performance and durability with a rated flow of 40 L/min (10.5 US gpm) and a maximum pressure of 250 bar (3600 psi).

Serie P40 Valvola direzionale monoblocco Parametri
Metodo di Controllo Manuale, Pneumatico, Elettropneumatico, Elettroidraulico, Solenoide, Idraulico, Idraulico e Manuale, Cavo, Joystick, Solenoide e joystick, Manuale e joystick, A solenoide e a cavo
Spoo 1 Spola, 2 Spole, 3 Spole, 4 Spole, 5 Spole, 6 Spole, 7 Spole
Intervallo di temperatura ambiente -40°C to +80°C (-40°F to +176°F)
Tipo di struttura Valvola monoblocco
Sezione Sezione 1, Sezione 2, Sezione 3, Sezione 4, Sezione 5, Sezione 6, Sezione 7
Intervallo di viscosità operativa 15 - 75 mm²/s (15 cSt to 75 cSt)
Portata nominale 40 L/min (10.5 US gpm)
Pressione massima 250 bar (3600 psi)
Attacco di ingresso G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Attacco di uscita G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Dimensione attacco G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-G12-G38 Hydraulic Valve is a premium choice for demanding applications. It features a robust monoblock construction with 4 sections, providing excellent control and responsiveness. The manual control method ensures precise operation and ease of use. This valve is designed to handle high flow rates up to 40 L/min (10.5 US gpm) and withstand pressures up to 250 bar (3600 psi). With its wide operating viscosity range (15-75 mm²/s) and ambient temperature range (-40°C to +80°C), the valve is suitable for a variety of environments. It is specifically designed for use in telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. This makes it a versatile and reliable choice for a wide range of industrial equipment.
