P120-G1-OT Valve: Technical Data, CAD Drawings, and Support

Metodo di Controllo:Manuale

Spoo:3 Spole

Portata nominale:120 L/min (31,7 US gpm)

Pressione massima:250 bar (3600 psi)

Attacco di ingresso:G1

Attacco di uscita:G1

Dimensione attacco:G1

Marchio:BXHS

Tipo di prodotto:Valvola direzionale monoblocco

Serie di prodotti:Serie P120 Valvola direzionale monoblocco

Dimensioni dell'imballaggio:37*37*18

Peso lordo:24.10 kg

Disponibilità: In magazzino

1339 Le visualizzazioni cercano questo prodotto

P120-G1-OT Valve: Technical Data, CAD Drawings, and Support

P120-G1-OT Valve: Technical Data, CAD Drawings, and Support

P120-G1-OT Valve: Technical Data, CAD Drawings, and Support drawing image

The P120-G1-OT Hydraulic Forward And Reverse Valve is a high-performance, manual control monoblock valve designed for a variety of construction, material handling, and industrial applications. It features a 3-section design, 120 L/min rated flow, and a maximum pressure of 250 bar.

Serie P120 Valvola direzionale monoblocco Parametri
Metodo di Controllo Manuale, Cavo, Joystick, Manuale e joystick
Spoo 1 Spola, 2 Spole, 3 Spole, 4 Spole
Portata nominale 120 L/min (31,7 US gpm)
Pressione massima 250 bar (3600 psi)
Attacco di ingresso G3/4, G1, M27×2.0, SAE 14, SAE 16, 3/4 NPT, 1 NPT, M36×2
Attacco di uscita G1, SAE 16, 1 NPT, M36×2
Dimensione attacco G3/4, G1, M27×2.0, SAE 14, SAE 16, 1 NPT, M36×2
Sezione Sezione 1, Sezione 2, Sezione 3, Sezione 4
Tipo di struttura Valvola monoblocco
Intervallo di temperatura ambiente -40°C to +80°C (-40°F to +176°F)
Intervallo di viscosità operativa 15 - 75 mm²/s (15 cSt to 75 cSt)

This P120 Series hydraulic valve is a 3-section, manual control monoblock valve with a rated flow of 120 L/min and a maximum pressure of 250 bar. It is ideal for use in a wide range of applications, including construction equipment (telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders), material handling equipment (telehandlers, midi-excavators, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, dumpers), and agricultural machinery. The valve operates with an operating viscosity range of 15 - 75 mm²/s and is suitable for ambient temperatures ranging from -40°C to +80°C. The P120-G1-OT valve offers reliable performance and durability, making it an excellent choice for demanding applications.
