Monoblock Directional Valve - PC-1220-250-1 Series | Wholesale & OEM

Metodo di Controllo:Pneumatico

Spoo:1 Spola

Portata nominale:Portata nominale 220 L/min (58.1 US gpm)

Pressione massima:250 bar (3600 psi)

Attacco di ingresso:G1

Attacco di uscita:G1

Dimensione attacco:G1

Marchio:BXHS

Tipo di prodotto:Valvola di Ribaltamento

Serie di prodotti:PC-1220 Series Valvola di Ribaltamento

Dimensioni dell'imballaggio:40*18*16

Peso lordo:6.50 kg

Disponibilità: In magazzino

1259 Le visualizzazioni cercano questo prodotto

Monoblock Directional Valve - PC-1220-250-1 Series | Wholesale & OEM

Monoblock Directional Valve - PC-1220-250-1 Series | Wholesale & OEM

Monoblock Directional Valve - PC-1220-250-1 Series | Wholesale & OEM drawing image

The Selonoid Hydraulic Valve Monoblock Directional Valve - PC-1220-250-1 Series is a high-performance valve designed for use in a variety of construction and industrial applications. It features a robust monoblock design and a rated flow of 220 L/min, making it suitable for demanding applications.

PC-1220 Series Valvola di Ribaltamento Parametri
Metodo di Controllo Pneumatico
Spoo 1 Spola
Portata nominale 220 l/min (58 gpm US)
Pressione massima 250 bar (3600 psi)
Attacco di ingresso G1
Attacco di uscita G1/2, G1
Dimensione attacco G1/4
Sezione Sezione 1
Tipo di struttura Valvola monoblocco
Intervallo di temperatura ambiente -40°C to +80°C (-40°F to +176°F)
Intervallo di viscosità operativa 15 - 75 mm²/s (15 cSt to 75 cSt)

The Selonoid Hydraulic Valve Monoblock Directional Valve - PC-1220-250-1 Series is a reliable and durable valve designed for use in a variety of construction and industrial applications. It is a pneumatic control valve with a single section, monoblock structure, and a rated flow of 220 L/min (58 US gpm). The valve can withstand a maximum pressure of 250 bar (3600 psi) and operates within a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). It features a single spool and is part of the PC-1220 Series. The valve can be used in a wide range of applications including material handling, construction and earth moving, agriculture, and industrial vehicles. This valve is suitable for use in various equipment such as telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. The valve is available for wholesale and OEM orders.
