Produzione e consegna
Tempi di produzione di 15-30 giorni



This 6 cc/rev Hydraulic Gear Pump is designed for various applications in construction, agriculture, industrial vehicles, and material handling. It features a displacement of 10 cc/rev, a rated pressure of 20 MPa (2900 psi), and a rated speed of 2000 r/min.
| Serie CBHS-FL3 Pompa a ingranaggi idraulica Parametri | |
|---|---|
| Cilindrata | 10 cc/giro, 4 cc/giro, 20 cc/giro, 16 cc/giro, 14 cc/giro, 6 cc/giro |
| Pressione nominale | 20 MPa (2900 psi) |
| Pressione massima | 25 MPa (3625 psi) |
| Velocità nominale | 2000 giri/min |
| Velocità massima | 3000 giri/min |
| Rotazione | L: Sinistra (in senso antiorario), R: Destra (in senso orario) |
| Materiale | Alluminio |
| Struttura | Pompa a ingranaggi esterna |
| Versione flangia | Flangia a forma ovale di tipo A |
| Tipo di albero | H: Scanalatura rettangolare, X: Scanalatura evolvente, P: Chiave semplice |
This high-performance 6 cc/rev Hydraulic Gear Pump is engineered for demanding applications. It boasts a displacement of 10 cc/rev, a rated pressure of 20 MPa (2900 psi), and a rated speed of 2000 r/min, capable of reaching a maximum speed of 3000 r/min. Built with an internal gear pump structure and crafted from durable aluminium, this pump features an A-Oval Flange and a Plain Key shaft. It belongs to the CBHS-FL3 Series and is specifically designed for use in various heavy-duty equipment, including telehandlers, forklifts, mini-excavators, skid steer loaders, compact wheel loaders, tractors, front-end loaders, harvesters, balers, and sprayers. Its reliability and performance make it an ideal choice for manufacturers and distributors seeking high-quality hydraulic gear pumps for diverse applications.
